KALEA-INFORMATIQUE OCP 3.0 10G 25G Fiber 4 Port SFP+ SFP28 NIC Network Controller Card with Intel E810 Chipset

Open Compute Project (OCP) 3.0 x8 PCIe 3.0 server card offering four 25G SFP28 ports (SFP+ 10G compatible).

Compatibility: Microsoft Windows Server 2022, 2019, 2016, Microsoft Azure Stack HCI, Microsoft Windows 11, 10, 8, 7, Vista, VMware ESXi, Linux, FreeBSD...

Chipset: Intel E810. OCP NIC 3.0 Small Form Factor PCIe 4.0 Adapter Four 25GbE SFP28 or 10GbE SFP+ ports. PCI Express (PCIe) 3.0 x8

Supported protocols: Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet. Compatible with IEEE 802.1p, IEEE 1588v2, IEEE 802.3by, OCP 3.0, IEEE 1588v1. Communications supported: TCP/IP, UDP/IP, iWARP, HTTPs, MCTP, RBT. Remote administration: SNMP, RMON, HTTPS, SMBus, PLDM

Chipset function list: Flow control, VLAN support, WFQ, ACL support, QoS, RDMA support, VMDq, UEFI support, SR-IOV, WDT, PTP, DSCP support, DDIO Technology, Storm Control, IP SLAs, NC-SI, VXLAN, NVGRE, RoCE v2, Intel Flow Director, FPP, intelligent offloads, Advanced Packet Filtering, DPDK, IETET. F mapping, VLAN Tagging, congestion management, NFV, VMLB, GENEVE support, NVMe-oF, On-chip QoS and Traffic Management, DDP, ADQ, ZTNA, MPLS, Adaptive Virtual Function, VxLAN-GPE with NSH.

TCP/UDP/IP stateless offload. LSO.LRO file. unloading the checksum. Hardware unloading of the encapsulation and decaplation of NVGRE and VXLAN overlay networks. SR-IOV, multifunction, enhanced QoS, VMware support. Up to 256 virtual functions and 8 physical functions per port. Supports OpenMPI, IBM PE, OSU MPI, Intel MPI protocols.

Dimensions: 110 mm x 68 mm. Compatible with Windows 7 8 8.1 10 11 (32- 64bit), Windows Server 2008R2 2012R2 2016 2019, FreeBSD, Linux, VMWare ESXi.
