KALEA-INFORMATIQUE PCIe Gen 4.0 x4 Dual LAN Ethernet RJ45 10G 5G 2.5G 1G 2 Port Network Controller Card with Intel E610 Chipset

High Performance Network Card: Dual Port 10 Gigabit Network Card, based on Intel E610 Controller. Thanks to its PCIe Gen 4.0 x4 interface, it offers high performance. It also includes advanced features such as PXE/UEFI, Wake-on-LAN, SR-IOV and IEEE 1588 PTP

System & hardware compatibility: Compatible Windows, Windows Server, Deepin, Ubuntu, RHEL/CentOS, OpenEuler, Fusion OS, Kylin OS, OpenKylin. For PCIe Gen 4.0 or higher port in x4, x8 or x16

Main technical specifications: PCI Express 4.0 x4 interface, 2 RJ45 Ethernet copper ports, Intel E610 controller, 100M / 1G / 2.5G / 5G / 10G (self-adaptive), Jumbo frames support up to 9.7 KB. Supported standards: IEEE 802.3an (10GBASE-T), IEEE 802.3 (1000BASE-T / 100BASE-TX), IEEE 802.1Q (VLAN), IEEE 1588 (PTP synchronization), IEEE 802.3az (energy efficiency), IEEE 802.1BR, 802.1 Qbg, P8 02.1AE (virtualization and security)

Advanced features and cabling compatibility: PXE / UEFI (network boot), Wake-on-LAN (remote wake), SR-IOV (network virtualization), IEEE 1588 PTP (precision synchronization). Wiring compatibility: 10G Cat6 (up to 55m), Cat6a or higher (up to 100m), 5G Cat6a or higher (up to 100m), 2.5G Cat5e (up to 30m), Cat6 or higher (up to 100m), 1G/100M Cat5e or higher (up to 100m) m)

Physical characteristics and content: Maximum consumption approx. 4 W, operating temperature -10 °C to 60 °C, LED for connection and activity, supplied with two brackets (low profile and high profile). Dimensions: 125 mm x 68.9 mm x 10 mm
