EXSYS Exsys EX-13074HM USB 2.0 to 4 x Serial RS-232 FTDI Chip Set Metal Housing

The EX-13074HM USB to Serial RS-232 in a metal housing, provides four SerielleRS-232 high performance UART 16C550 outputs. The EX-13074HM USB 2.0 to Serial RS-232 in a metal housing provides four serial RS-232 high performance UART 16C550 outputs. It has been developed to extend four additional serial outputs in a robust metal housing for desktop computers or notebooks via the USB 2.0 bus. The EX-13074HM has LED indicators for data transfer to each port and comes with two brackets for wall mounting and a DIM rail kit for mounting on a carrier rail in a 19 inch rack. A terminal block and a DC socket are available for optional power supply. • Interface: RS-232 V.24 • FIFO buffer: 16C550 with 16bytes • I/O addresses and interrupt: are assigned by the operating system. • Data bits: 7, 8 / stop bits: 1, 1.5, 2 / parity: none, even, odd, space, mark. • Signals RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND • Power supply from USB bus (bus power). • LED for TX and RX active display. • Chip set: FTDI
