EXSYS EX-42032-2X Serial RS-232/422/485 PCI Card, POS Adjustable (FTDI Chip Set)

The EX-42032 PCI I/O card provides two high performance 16C550 UART serial RS-232, RS-422 and RS-485 serial ports. It is designed to extend two additional serial ports for PC, small workstation or server via the PCI– or PCI-X bus. +5V and +12V can be configured on pin 9 of the serial connector as POS system (Power over System). The card is fully plug and play compatible. It supports the features ATTATM Auto RS-485 Transmitter. For each port, the transmission type RS-232, 422 or 485 can be set individually. • Interface: RS-232 V.24 / RS-422 / RS-485 • ±15kV IEC1000-4-2 ESD protection for RS232 I/O's • FIFO Buffer 16C550 with 16 byte • I/O addresses and interrupt are assigned by the operating system • Data bits: 7 and 8 / stop bits: 1, 1.5, 2. • Parity: none, even, odd, space and mark. • Supports ATTATM car transmitter. • Termination RS-422/485 - 120 Ohm can be switched on and off
