Sandvik Coromant DNGA150412S02035A7015 T-Max P Insert for Turning (Pack of 5)

Part of the T-Max P product family. T-Max P is your first choice for general turning, stretching from small components to heavy machining. The inserts fit into all Sandvik Coromant high performance holding systems and can be used in a variety of applications in all materials. Geometries specifically designed for high pressure coolant are available for steel, stainless steel and HRSA materials. PRODUCT SPECIFICATION: Material classification (TMC1ISO): H (ISO H Hardened steel); Application: Finishing ; Grade: 7015 ; ISO Cutting Tool Material: BC ; Coating Process Type: PVD ; Coating Type: TiN ; Substrate Type: CBN ; AN, Clearance Angle Major: 0 deg ; BN, Face Land Width: 0.20 mm ; BN, Face Land Width: 0.007874 inch ; CTPT, Operation Type: Finishing ; CUTINT_SIZESHAPE, Insert Size And Shape: DN1504 ; GB, Face Land Angle: 35 deg ; HAND, Hand: N ; IC, Inscribed Circle Diameter: 12.7 mm ; IC, Inscribed Circle Diameter: 0.5 inch ; LE, Cutting Edge Effective Length: 2.4 mm ; LE, Cutting Edge Effective Length: 0.094488 inch ; RE, Corner Radius: 1.1906 mm ; RE, Corner Radius: 0.04689 inch ; S, Insert Thickness: 4.7625 mm ; S, Insert Thickness: 0.18748 inch ; SC, Insert Shape Code: D ; WEP, Wiper Edge Property: 0 ; WT, Weight Of Item: 0.0116 kg ; WT, Weight Of Item: 0.0255 lbs ;
