Sandvik Coromant 435.B-0601-A1-XFH10F CoroReamer 435 solid carbide reamer

Part of the CoroReamer 435 product family. CoroReamer 435 is a multi-application, versatile and high speed reamer, suitable for a wide range of materials. It gives you really close hole tolerances and high-quality surface finish thanks to internal coolant, the cutting edge geometry and extremely unequal spacing of the cutting edges. PRODUCT SPECIFICATION: Grade: H10F ; ISO Cutting Tool Material: HF ; Coating Type: Uncoated ; Substrate Type: WC ; ADINTMS, Adaptive Interface Machine Direction: Cylindrical shank (DIN6535-HA) -metric: 6 ; BSG, Basic Standard Group: COROMANT ; CNSC, Coolant Entry Style Code: 1: axial concentric entry ; CP, Coolant Pressure: 20 bar ; CP, Coolant Pressure: 290.076 lbf/in2 ; DC, Cutting Diameter: 6.01 mm ; DC, Cutting Diameter: 0.236614 inch ; DCON, Connection Diameter: 6 mm ; DCON, Connection Diameter: 0.23622 inch ; L, Cutting Edge Length: 12 mm ; L, Cutting Edge Length: 0.472441 inch ; LCF, Chip Flute Length: 15.6 mm ; LCF, Chip Flute Length: 0.614173 inch ; LF, Functional Length: 74.1 mm ; LF, Functional Length: 2.91732 inch ; LU, Usable Length: 39 mm ; LU, Usable Length: 1.53543 inch ; NOF, Flute Count: 4 ; NORGMX, Maximum Regrinds: 0 ; OAL, Overall Length: 75 mm ; OAL, Overall Length: 2.95276 inch ; PHD, Premachined Hole Diameter: 5.8 mm ; PHD, Premachined Hole Diameter: 0.228346 inch ; PLGL, Plug Length: 0.9 mm ; PLGL, Plug Length: 0.035433 inch ; RPMX, Rotational Speed Maximum: 5084 r/min ; TCDCON, Connection Diameter Tolerance: h6 ; TCHA, Achievable Hole Tolerance: H7 ; TCHAL, Achievable Hole Tolerance Lower: 0 mm ; TCHAL, Achievable Hole Tolerance Lower: 0 inch ; TCHAU, Achievable Hole Tolerance Upper: 0.015 mm ; TCHAU, Achievable Hole Tolerance Upper: 0.000591 inch ; WT, Weight Of Item: 0.038 kg ; WT, Weight Of Item: 0.0836 lbs ;
