Jung 211GDE Dimming Switch with Radio Receiver

Jung 211GDERotary dimmer Rotary dimmer with pressure change switch Intended Use Switching and dimming of light bulbs and HV halogen lamps Installation in appliance box according to DIN 49073 Suitable for mixed operation up to the specified output Product features Dimming principle phase cut Electronic short-circuit protection with permanent switch-off after 7 seconds at the latest Electronic over-temperature protection Two-way circuit in combination with change-over switch possible Performance additives (only for 230 V light bulbs and 230 V halogen lamps): Item number: 246 EB: maximum 10; Load must be "split" between dimmer and power boost. Covers: Series AS/A: Item no.: A 1540 .. CD series: Item no.: CD 1540 .. SL series: Item no.: SL 1540 .. LS Series: Item no.: LS 1940 .., .. 1940. Depending on the type of installation, the maximum power consumption can be reduced: - 10% for every 5 ° C above an ambient temperature of 25 ° C - 15% for installation in wood, plasterboard or hollow wall - 20% for installation in multiple combinations Specifications Nominal voltage: AC 230/240 V ~, 50 Hz Connected load: 100 1000 W Dimming principle: Phase cut Load types: 230/240 V light bulbs 230/240 V halogen lamps Mixed loads of the specified load types. Connection: Screw terminals maximum clampable wire cross section: 2 x 2.5 mm2 or 1 x 4 mm2 Specifications
