Eltako Universal Dimmer Switch 230 V, Power MOSFET, ESL LED up to 400 W, 1 Piece, EUD61NPN-230V, 400 W, Blue

Universal Dimmer Switch Power MOSFET up to 400W. Automatic lamp detection. Stand-by loss only 0.1 watts. Minimum brightness or dimming speed adjustable. With nursery and snooze switch. For recessed mounting. 45 mm long, 45 mm wide, 18 mm deep. Universal dimmer switch for lamps up to 400 W, depending on the ventilation conditions. Dimmable energy-saving bulbs ESL and dimmable 230 V LED bulbs additionally depending on the lamp electronics. Switching in zero crossing with soft on and soft-off for lamp protection. Control voltage, supply voltage and switching voltage 230 V. No minimum load required. Short control commands turn on/off, permanent control changes brightness up to the maximum value. An interruption of the control changes the dimming direction. The set brightness level remains stored when switched off (memory). In the event of a power failure, the switching position and the brightness level are stored and, if necessary, is switched on when the supply voltage is returned. Automatic electronic overload protection and over-temperature shutdown. With the top %lamp/dim-speed rotary switch, either the dimming speed can be set or the minimum brightness (fully dimmed). With the dimming speed, the duration of soft on and soft off is also changed. The lower rotary switch determines during operation whether automatic lamp detection should work, or special comfort positions: AUTO allows dimming of all lamp types. EC1 is a comfort position for energy-saving lamps, which have to be switched on with an increased voltage due to the design, so that they switch on again safely when dimmed even cold. EC2 is a comfort position for energy-saving lamps, which cannot be switched on again due to their design when dimmed down. Therefore Memory is switched off in this position.
