Springer Ultra-Low-Voltage Frequency Synthesizer and Successive-Approximation Analog-to-Digital Converter for Biomedical Applications (Analog Circuits and Signal Processing)

This book introduces the origin of biomedical signals and the operating principles behind them and introduces the characteristics of common biomedical signals for subsequent signal measurement and judgment. Since biomedical signals are captured by wearable devices, sensor devices, or implanted devices, these devices are all battery-powered to maintain long working time. We hope to reduce their power consumption to extend service life, especially for implantable devices, because battery replacement can only be done through surgery. Therefore, we must understand how to design low-power integrated circuits.Both implantable and in-vitro medical signal detectors require two basic components to collect and transmit biomedical signals: an analog-to-digital converter and a frequency synthesizer because these measured biomedical signals are wirelessly transmitted to the relevant receiving unit. The core unit of wireless transmission is the frequency synthesizer, which provides a wide frequency range and stable frequency to demonstrate the quality and performance of the wireless transmitter. Therefore, the basic operating principle and model of the frequency synthesizer are introduced. We also show design examples and measurement results of a low-power low-voltage integer-N frequency synthesizer for biomedical applications. The detection of biomedical signals needs to be converted into digital signals by an analog-to-digital converter to facilitate subsequent signal processing and recognition. Therefore, the operating principle of the analog-to-digital converter is introduced. We also show implementation examples and measurement results of low-power low-voltage analog-to-digital converters for biomedical applications. From the Back Cover This book introduces the origin of biomedical signals and the operating principles behind them and presents the characteristics of common biomedical signals for subsequent signal measurement and judgment. Since biomedical signals are captured by wearable devices, sensor devices, or implanted devices, these devices are all battery-powered to maintain long working time. We hope to reduce their power consumption to extend service life, especially for implantable devices, because battery replacement can only be done through surgery. Therefore, we must understand how to design low-voltage low-power integrated circuits.  Provides necessary background information on biomedical signals and proceeds with design considerations for low supply voltage analog circuits; Describes design techniques for not only frequency synthesizers and ADCs, but also the ultra-low voltage design techniques of these circuits; Demonstrates examples to overcome typical design challenges.   About the Author Chung-Chih Hung received the B.S. degree in electrical engineering from National Taiwan University, Taipei, Taiwan, in 1989, and the M.S. and Ph.D. degrees in electrical engineering from The Ohio State University, Columbus, Ohio in 1993 and 1997, respectively. From 1997 to 2003, he worked for several IC design companies in San Jose, CA and San Diego, CA, where he held analog circuit design manager and director positions and successfully designed many chips in mass production. Since 2003, he has been with National Yang Ming Chiao Tung University, Hsinchu, Taiwan, where he is currently a Professor in the Department of Electrical and Computer Engineering. He is the Deputy Director of the Biomedical Electronics Translational Research Center (BETRC) in National Yang Ming Chiao Tung University. Dr. Hung has served on the Steering Committees of the IEEE MWSCAS and technical program committees of some IEEE conferences. He and his students have won several Best Paper Awards at international conferences. He has been the Deputy Editor-In-Chief of Analog Integrated Circuits and Signal Processing since 2013 and currently serve as Associate Editor of IEEE Transactions on Biomedical Circuits a
