BGS 63407 Car Diagnostic Multimeter

Perfect tool for diagnosing automotive electrics | compact, lightweight and handy | digital multimeter, oscilloscope and signal generator | voltage measurements, for DC and AC voltage | input impedance: 2 to 3 MΩ below 160 VC, 10 MΩ over 160 V | maximum input voltage: 1000 Vpp, bandwidth: 500 kHz

Current measurements, for DC and AC | Measuring range 0 mA to 200 mA fused with 0.5 A (self-resetting) | Measuring range 200 mA - 20 A fused with 15 A (self-resetting) for 10 A continuous measurements, 20 A short-term measurements | Resistance measurements for evaluating Resistance and temperature sensoren

Frequency measurements show pulsating voltage in Hz. Starter system test for testing the starting and charging system. Injector test to control the injector and detection of the real-time signal. Relay test for controlling the relay. K-line signal, outputs a 5 V rectangular signal, baud rates: 1200, 2400, 4800, 96. 000, 10400, 19200, 38400, 57600, 115200

Sine wave signal, 5 V signal, outputs a sine signal with a peak valley value of 0 V to 4.5 V. Signal frequency from 1 Hz to 10 kHz, duty ratio: 10 % to 90 %. Oscilloscope for displaying ignition pulse signal, camshaft signal, crankshaft signal, wheel speed sensor signal, oxygen sensor. signal, CAN-bus signal, Data, K line data, large illuminated LCD display, display resolution: 240 x 320 pixels, updatable, working temperature max. : 40 °C

Includes the following adapter cable: C01 adapter: DC connection for connection to vehicle battery | C03 adapter cable: detecting the line signal of higher voltages | C04 adapter cable: DC connection, connected to the battery terminal cable
