UNI-T Uni-T PRO UT191T / MIE0369 / True RMS/Torch

Technical details: Measuring ranges: DC voltage: 600 mV / 6 V / 60 V / 600 V ± (0.5% +3). AC voltage: 600 mV / 6 V / 60 V / 600 V ± (0.7% +3) (measured current frequency range: 45 ~ 400 Hz). AC voltage for low internal impedance sources: 600V (2%+5) AC AC voltage with low-pass filter switched on: 600 V (2%+5) DC current: 600µA, 6000µA / 60mA / 600mA / 6A / 20A (0.8%+3) AC current: 600µA, 6000µA / 60mA / 600mA / 6A / 20A (1%+3) (measured current frequency range: 45~400Hz) Resistance: 600 Ohm / 6 kOhm / 60 kOhm / 600 kOhm / 6 MOhm / 60 Mohm ±(0.8%+2) Capacity: 6 nF / 60 nF ~ 600 µF / 6 mF ~ 60 mF ± (3%+5) Frequency: 10 Hz ~ 1 MHz ± (0.1% + 4). Filling factor: 0.1% ~ 99.9% ±(0.2%+5). Temperature: -40oC ~ 400oC ±(1%+2); -40oF ~ 752oF ±(1%+4). Diode test Continuity test of the circuit. ADDITIONAL FEATURES Automatic/manual change of measuring ranges True RMS measurement MAX/MIN/PEAK RECORDING Freeze last display Relative measurement mode. Backlit LCD screen. Analogue bargraph 31 segments. Low battery indicator. Automatic shutdown. flashlight Maximum display: 6000 General features: Power supply: 9V battery Size of the display: 58 x 42 mm. Product dimensions: 180 x 87 x 59 mm. Product weight: 428 g Accessories: battery, test leads, temperature sensor, case.
