UNI-T UT161D/MIE0433 Digital Universal Meter Voltage Tester, Current AC/DC, Capacity, Circuit Test and Diodes, Temperature Measurement

The UT161D multimeter is a multifunctional automatic meter highly reliable, safe, durable and accurate multimeter, which is CE certified and suitable for the European market. The display of this multimeter is an illuminated LCD display (dark data on bright background) with ±6000 place number. The display has a refresh rate of 2-3 times per second, also contains an analogue ruler so-called bargraph with 31 segments multimeter measures AC and DC voltages up to 1000 V and has an acoustic and optical warning to achieve the maximum voltage/current or temperature. Allows non-contact detection of AC cables. Includes USB cable with optoelectric converter for data transfer to the PC. Powered by four AAA (R03). The meter will automatically turn off after 15 minutes of inactivity (function can be temporarily switched off). The power inputs are secured by pipe fuses and the fuses can be tested without opening the device. Mass cards. DC voltage: 1000V ±(0.5%+3) AC Voltage: 1000V ±(1%+3) DC Current: 20A ±(1%+2) AC Current: 20A ±(1.2%+5) Resistance: 60 Mohm ±(1%+2) Capacity: 60mF ±(3%+5) Frequency: 10MHz ±(0.1%+4) Temperature: -40°C ~ 1000°C ±(1%+3), -40°F ~ 1832°F ±(1%+6). Filling factor: 0.1% ~ 99.9% ±(2%+5) Diode test Continuity test. Additional functions: Automatically change the measuring ranges True RMS measurement. Measurement of electromagnetic field strength. Low pass filter. Freeze the last display. Peak value recording. Relative measurement mode. Max/min/peak value recording. Analogue bargraph: 31 segments Automatic shutdown. Maximum reading: 6000 Features: Power supply: 4 x 1.5 V battery (R03) Dimensions: 190 x 90 x 50 mm Product weight: 350g Accessories: batteries, test leads, USB cable, temperature probe, attachment
