£42.72

Schneider Electric DPER32 Easy TeSys Thermal Overload Relay with Manual/Automatic Reset, Screw Clamp Terminals | Used with Air Conditioner, Heat Pump, HVAC, AC Compressor and More, 23-32Amps

Name: Schneider Electric DPER32 Easy TeSys Thermal Overload Relay with Manual/Automatic Reset, Screw Clamp Terminals | Used with Air Conditioner, Heat Pump, HVAC, AC Compressor and More, 23-32Amps
Brand: Schneider Electric
Price: 42.72 GBP
Availability: InStock

DPER32

Overload Relays

This is the usual price. Wait for it to drop, or tell us your number.

£43 today · usual range £35–£45 · best ever £35

NEW HERE?

Amazon shows you one price. We show you all of them.

Tosheroon watches Amazon prices so you don't have to. Every product on Amazon has a price history — we make it visible. Set the price you'd actually pay, and we'll email you the second it gets there. No app, no account, one email.

WHAT'S ON THIS PAGE

↓ Price chart
when this has been cheap or pricey

↓ Forecast
where the price is heading next

↓ Statistics
all-time high & low, recent range

↑ Price alert
name your number, we'll email you

Price History & Forecast

Grey patches = out of stock. Cheaper = lower on the chart. Hover for exact prices.

Last 51 days · 51 data points (no recent data)

Historical

Generating forecast…

Price Distribution

Price distribution over 51 days • 4 price levels

Days at Price

Current Price

Price Analysis

Most common price: £35 (28 days, 54.9%)

Price range: £35 - £45

Price levels: 4 different prices over 51 days

Description

Easy TeSys DPER thermal overload relay, 32A/690V, thermal setting range 23-32A, tripping class 10, for protection of 3-phase motors 15kW@400V. Differential device with phase failure and load unbalance detection. It provides a thermal adjustement dial, a manual-automatic reset selector, a test selector for simulation of a tripping, reset and stop buttons, a flag indicator and 2 auxiliary contacts 1NO+1NC for fault signalling. Settings are protected by a transparent cover lockable by sealing.Connection by screw clamp terminals, the DPER series of thermal overloads connects directly to the bottom terminals of the 3-pole DPE contactors series ranging from 9-38Amps. Mounting on DIN rail or screw fixing, separated from the contactor. Multi standards certified (IEC, cUL), Green Premium compliant (RoHs/Reach).

Key Features

This thermal overload relay can be used in a network frequency of 0-4000hz, the rated insulation is 600V cUL / 690V IEC, and tripping class 10, for protection of 3-phase motors for HVAC, elevators, pumps or compressors, and agriculture

It features a compact and modular design, making it an ideal solution for space-constrained applications and can be quickly and easily configured to meet the needs of your specific application

A reliable and cost-effective solution for protecting your motor against overloads, phase failures, and phase unbalances; durable, compact design to protect from dust and other environmental elements

The thermal overload relay has phase-break protection, manual and automatic reset, temperature compensation, trip indication, test button, stop button

Compatible with these Schneider Electric contactors DPE38G7, DP38BL, DPE38U7, DPE38B7 and Schneider Electric’s Easy TeSys GP2E manual motor starter series; use with LAD7B106 Schneider Electric mounting adaptor

Product Specifications

Brand: Schneider Electric
Model: DPER32
Size: 23-32a
ASIN: B09B2PNP7K
Category: Business, Industry & Science > Industrial Electrical > Controls & Indicators > Relays > Overload Relays
Domain: Amazon UK
Release Date: 11 April 2025
Listed Since: 17 May 2024
