wirenco Wirenco 6/2 NM-B, Non-Metallic, Sheathed Cable, Residential Indoor Wire, Equivalent to Romex (75Ft Cut)

Applications: Non-metallic sheathed NM-B cable is used in normally dry installations in residential wiring, as branch circuits for outlets, lighting and other residential loads. Its applications are outlined in NEC 2008 and NEC 2011 Article 334. NM-B is rated at 600 volts and although it is rated at a conductor temperature of 90°C dry , its ampacity is limited to 60°C according to the NEC 2008 and NEC 2011. It may be fished through masonry or tile walls, where not exposed or subject to excessive moisture or dampness. NM-B cables are LEAD FREE and RoHS compliant. Equivalent to Romex NM-B. Standards: Meets or exceeds all applicable ASTM specifications UL Standard 83: Thermoplastic Insulated Wires and Cables UL Standard 719: Non-Metallic Cables Federal Specification A-A-59544 and requirements of the NEC Voltage rating - 600 volts Constrction: Insulation:Color coded polyvinyl chloride (PVC) compound with a nylon covering meeting the required thickness of Type THHN. Conductor insulation is rated 90℃C Sheath:30 mil color coded PVC sheath rated 90℃C is applied over the completed assembly Specifications: Size:6 AWG Number of Conductors:2 PVC Insulation Thickness:0.76 mm / 0.029 inches Ground Wire Size:10 AWG Nylon Thickness:0.13 mm / 0.005 inches Nominal Cable Dimensions:8.1 x 17.3 mm / 0.31 x 0.68 inches Weight per Foot: 0.255 lbs Allowable Ampacity: 55 Amps
