INTELLINET NETWORK SOLUTIONS Intellinet Network Bulk Cat7 Cable, 23 AWG, Solid Wire, 305 m, Grey, Copper, S/FTP, LSZH, CPR-Dca Rated, Drum

• S/FTP • CPR-Dca Rated (Construction Products Regulation) • Standards tested; meets or exceeds current Cat7 standards • Suitable for building-structure cabling in secondary and tertiary areas • Recommended for 10/100/1000/10GBase-T, ATM, FDDI, Video, ISDN, Multimedia and PoE applications • 305 m cable on drum The Intellinet Network Solutions Cat7 S/FTP Installation Cable has a cable construction of 4x2x AWG23/1 and reaches a transmission frequency up to 600 MHz. The halogen-free cable jacket conforms to IEC 60332-3-24, FRNC-C, LSZH-3 and EuroClass CPR-Dca standards. The cable is best suited for building-structure cabling in secondary and tertiary areas. Specifications Certification and Standards • IEC61156-5 • ISO/IEC 11801 • CPR-Dca • RoHS, REACH Technical Specifications • Conductor: solid, bare copper • AWG 23 • Conductor diameter: 1/0.56 mm ± 0.008 mm • Insulation: FMPE • Average thickness: 0.395 mm • Insulation diameter: 1.35 mm ± 0.05 mm • Aluminum foil on each pair • Braid: tinned copper • LSZH jacket • Rip cord Performance • Max. conductor DC resistance 20°C: 95 Ω/km • Delay skew: ≤ 25 ns/100 m • Pair-to-ground capacitance unbalance: ≤ 160 pF/100 m • Min. insulation resistance: 5000 MΩ/km • Resistance unbalance: ≤ 2% • Min. bend radius: 8 mm OD.
