Jung Standard Rotary Dimmer LED

Standard rotary attenuator led incremental control without end position; no satellite input Product characteristics the device works according to the principle of phase control of the front edge or the principle of phase control of the rear edge automatic adjustment of the regulation principle suitable for loading; the device can be operated without neutral conductor on by soft start preserving the bulb; on with the last brightness or ignition brightness saved the ignition brightness can be permanently save e; minimum brightness can be permanently stored electronic short-circuit protection with permanent shutdown no later than 7 seconds; electronic heating protection power extension possible by means of power reinforcements (ref.-no; ulz 1755 reg) accessory or pc i on al: LED compensation module, ref.-nº: km led 230 or technical data rated voltage: ca 230 V mains frequency: 50/60 hz; standby power: approx. 0.35 w power loss: approx. 2 W capacitive-inductive: no neutral conductor operation allowed: minimum load of 50 w; not applied to loads with high voltage LED and compact fluorescent lamps; connection: screw terminals power cable total length: max. 100 m - intended use switching and regulation of lighting; operation with suitable lid; installation in discharge box according to din 49073.
