Orbis Orbimat OB132612 Motion Sensor Detector Indoor Night Light Lamp

Suitable for all types of loads. <br />Universal mechanism box installation. <br />Timing, light sensitivity and adjustable detection field <br />LED control zero step relay <br />200o pick-up angle <br />Up to 6 metres of detection diameter <br />Concealed adjustment potentiometers <br />Permanent disconnection or accessible connection <br />Compatible with SIMON Series 27 <br />Nominal voltage <br />230 Vc.a. <br />Rated Frequency <br />50-60 Hz <br />Break Power <br />6 A / 230 Vc.a. cosφ = 1 <br />Power consumption <br />Less than 1 W <br />Contact type <br />Simple, with potential <br />Operating temperature <br />0 oC to +40 oC <br />Recommended maximum loads. <br />Incandescent type: 1,300 W <br />Voltage:1300VA <br />Low Voltage Halogen : 1300VA <br />Halogen 230 Vc.a. ): 1300 W <br />Energy saving lamps: 1300 VA <br />Downlight lamps: 1300 VA <br />LED lamps: 500 VA <br />Timing <br />1s to 20min approx. <br />Detection angle <br />200o <br />Detection Field <br />Adjustable from 0 to 6 m to 20 oC <br />Protection Class <br />II according to EN 60529 in assembly conditions <br />Corrects. <br />Type of protection <br />IP 20 according to EN 60529 <br />Installation <br />Recessed in universal mechanism boxes <br />Light sensitivity <br />5-2000 Lux <br /><br /><br />
