Citronic CSL Range | Compact Mixing Consoles with Effects | 10 Inputs

CSL Series Compact Mixing Consoles with DSP Designed primarily for venues and stage applications, but suitable for much, much more. A compact yet comprehensive solution for mobile PA, bars and special events. Balanced mic/line inputs and 2 stereo inputs, each with 3-band EQ and aux send. A 16 program DSP section with tap tempo can provide vocal effects and a 7-band graphic EQ facilitates global tone control. PRODUCT FEATURES: - 24-bit 16 program DSP effects - 48V phantom power for XLR inputs - 3-band EQ per channel - 7-band global graphic EQ - IEC mains powered - Balanced main outputs SPECIFICATION: - Power supply 230Vac, 50Hz (IEC) - Phantom power +48V (XLR inputs) - Power consumption 25W - Fuse T1AL - Input level +24dBu - Output level : line +26dBu - Frequency response 20Hz-30kHz (0.5dB) - CMRR >74dB (mic 1kHz) - THD +N 85dB (fader mute), >82dB (channel) - Noise rms : 22Hz-22kHz -122dBu (EIN), -82dBu (mix) - EQ: high 12kHz ±15dB shelving - EQ: mid 2.5kHz ±15dB band pass - EQ: low 80Hz ±15dB shelving - Input impedance : mic (balanced) 2k Ohms - Input impedance : line (balanced) 10k Ohms - Sensitivity : mic -60 to +14dBu - Sensitivity : line -40 to +14dBu - 2-track 2 x RCA in & out (-2dBu) - Effects 16 program DSP (24-bit sigma-delta, 40kHz) - Output impedance <75 Ohms - Headphone output 6.3mm jack, 30-600 Ohms VERSION SPEC: - Inputs : mic/line 6 x balanced XLRF/TRS jack - Dimensions 360 x 320 x 107mm - Weight 3.5kg
