KALEA-INFORMATIQUE PCIe 3.0 SAS 12GB 8 Internal Ports Controller Card with 1GB DDR3 Cache and Raid 0 1 5 6 10 50 60. Model LSI 9361-8i

Card in "OEM" version, i.e. delivered in neutral box and with drivers to download on the Broadcom website. It allows you to add 8 internal SAS ports to a PC or server through a PCIe 3.0 (or more) connector in 8x (or 16x). General Features: SAS3108 12Gbps dual-core ROC controller. 8 internal ports per 2 x SFF8643 Mini SAS HD connectors each supporting 4 drives. SAS 3.0 compatible 12Gb/s data transfer rate. 1GB 1866MHz DDR3 SDRAM Cache SAS bandwidth type Half Duplex, Bus x8, 12MB per port. PCIe 3.0, x8 bus Form factor: Low profile, comes with low and high profile brackets. Supports Passive Copper and Active Optical (external port only). Operating voltage +12V +/-8% 3.3V +/-9%. Consumption 13W. Environment: Operation from 0°C to 55°C, Storage from -45°C to 105°C, RH 5-90%. Lasts over 1,343,187 hours. RAID Specifications: RAID 0, 1, 5, and 6 / RAID spans 10, 50, and 60, OCE, RLM, Auto Resume, Load Balancing, Configurable bands (max 1MB), Fast initialization, SSD support, support up to 64 logical disks, COD, SMART, Hot Spare, Supports SES and SGPIO, Databolt bandwidth optimizer technology, Shielded state drive diagnostic technology. Certifications: EN55022, EN55024, EN60950, EN 61000-3-2, EN 61000-3-3 FCC Class A, Class B UL1950 UL CSA C22.2 VCCI RRL for MIC BSMI C-tick EMC: Class B-US (CFR 47, P15B) Canada (ICES-003) Japan (V-3/02.04) Europe (EN55022/EN55024) Australia/New Zealand (AS/NZS 3548) Safety: EN60950 Support: Microsoft Windows Server 2012/8 and 7/2008/Vista/2003, Linux, Solaris (x86), FreeBSD, VMware and more.
