TROTEC 3510003029 – BP 17 Pyrometer

With an optical resolution of 10 : 1, the pyrometer measures contactless measured temperature values in the range from -50 up to +380 °C. By the measurment of the temperature, you can choose the sensitivity levels from 1 °C, 3 °C and 5 °C- dependent on the reference temperature- wherby the exceeding or falling below the pre-selected differential value will be indicated by an acoustic and visual alarm function. Thanks to the selectable visual target laser, you can precisely determine the centre of the measured point. Moreover, the backlit display and the automatic switch-off function as well as the user-friendly pistol design of the infrared thermometer ensure effortless working. A few practical benefits: Non-contact surface temperature measurement from -50 °C to +380 °C Selectable visual targeting laser Measuring optics 10:1 Acoustic and visual alarm when exceeding/falling below a preselectable temperature difference Adjustable sensitivity levels: OFF/1 °C/3 °C/5 °C LED indication when exceeding/falling below the threshold Backlit display Automatic switch-off Battery status indication Technical data: Optical resolution (D:S): 10:1 Smallest measuring spot: 12.7 mm (distance: 127 mm) Infrared measuring range : -50 °C bup to +380 °C (-58 °F up to +716 °F) Accuracy max.: ±2.0 °C oder ± 2 °C of the measured value Surrounding conditions (operation): 0 °C up to +50 °C Surrounding conditions (storage): -20 °C up to +60 °C / max. 80% r.H. LCD-Display Type of protection: IP54 Reaction time: <0,5 second Spectral sensitivity: 8 - 14 µm Emission level: 0,95 Laser: Class 2 / Wavelength: 630 - 670 nm / Power: <1 mW DImensions: 185 x 40 x 135 mm Weight: 220 g
