Sandvik Coromant C5-MWLNL-22110-08 T-Max P Cutting Unit for Turning

Part of the T-Max P product family. T-Max P is your first choice for general turning, stretching from small components to heavy machining. The inserts fit into all Sandvik Coromant high performance holding systems and can be used in a variety of applications in all materials. Geometries specifically designed for high pressure coolant are available for steel, stainless steel and HRSA materials. PRODUCT SPECIFICATION: ADINTMS, Adaptive Interface Machine Direction: Coromant Capto (bolt and segment clamping) -size C5 ; BAMS, Machine Side Body Angle: 0 deg ; BAWS, Workpiece Side Body Angle: 0 deg ; BD1, Body Diameter: 32 mm ; BD1, Body Diameter: 1.25984 inch ; BMC, Body Material Code: Steel ; CNSC, Coolant Entry Style Code: 3: axial concentric and radial entry ; CP, Coolant Pressure: 10 bar ; CP, Coolant Pressure: 145.038 lbf/in2 ; CUTINT_MASTER, Part 2 Of Cutting Item Interface Identifiers: WNMG 080408 ; CXSC, Coolant Exit Style Code: 3: axial inclined exit ; DCON, Connection Diameter: 50 mm ; DCON, Connection Diameter: 1.9685 inch ; DMIN1, Minimum Bore Diameter: 40 mm ; DMIN1, Minimum Bore Diameter: 1.5748 inch ; DPC, Damping Property: 0 ; GAMO, Orthogonal Rake Angle: -6 deg ; HAND, Hand: L ; HF, Functional Height: 0 mm ; HF, Functional Height: 0 inch ; KAPR, Tool Cutting Edge Angle: 95 deg ; LAMS, Inclination Angle: -14 deg ; LF, Functional Length: 110 mm ; LF, Functional Length: 4.33071 inch ; LU, Usable Length: 88 mm ; LU, Usable Length: 3.46457 inch ; MIIDM, Master Insert Identification: WNMG 08 04 08 ; OHX, Maximum Overhang: 110 mm ; OHX, Maximum Overhang: 4.33071 inch ; PSIR, Tool Lead Angle: -5 deg ; RMPX, Maximum Ramping Angle: 0 deg ; TQ, Torque: 4.5 Nm ; TQ, Torque: 3.31903 ft lbs ; WF, Functional Width: 22 mm ; WF, Functional Width: 0.866142 inch ; WT, Weight Of Item: 0.956 kg ; WT, Weight Of Item: 2.1032 lbs ; Box Contains C5-MWLNL-22110-08 + incl. in box: 5431 125-021, Wedge set, (pcs. = 1, incl.); 5322 331-07, Shim, (pcs. = 1, incl.); 5313 022-03, Pin, (pcs. = 1, incl.); 174.1-864, Key, (pcs. = 1, incl.);
