DBR12 Active PA Speaker

Yamaha DBR amplified speaker systems offer excellent audio quality, reliability and portability in three affordable models. Using the latest DSP, engineers applied Yamaha's exclusive FIR-X tuning to optimize sound, and protection algorithms to give the DBR series maximum output power. DBR models are bi-amplified, using a separate power amplifier for the woofer and high-frequency driver, to provide accurate performance. The DBR12 represents the perfect balance between size and performance, with 1000W of power and amazing resolution at any output level. Ideal for front-of-house, floor monitoring or even stage accompaniments, the DBR12 is the ideal choice for a wide range of applications. Main features: System type: 2-way, Bi-amplified, Bass-reflex Frequency range: (-10 dB) 52Hz - 20kHz Coverage angle: H90° x V60° Constant directivity horn SPL max (Peak) IEC Noise @ 1 m: 131 dB SPL Crossover: 2.1 kHz FIR-X tuning ( FIF linear phase filter R ) Dynamic Rated Power: 1000 W (LF 800 W, HF 200 W) Continuous Rated Power: 465 W (LF: 400 W, HF: 65 W) Power Consumption: 74W LF Components: Cone 12", Coil 2", Ferrite Magnet HF Components: Tweeter 1.4" compression, Ferrite Magnet Input 1: Combo x2 1 Input 2: Combo x1 + RCA pin x 2 (unbalanced) Output: XLR3-32 x1 (CH1 Parallel Through or CH1 + CH2 Mix) Handles: 2 Side Hole 35 mm for stand Dimensions: 376 x H601 x 348 mm (including rubber feet) Weight: 15.8 kg.
