Monacor MONACOR SP-302PA Universal 100 Watt Rated 8 Ohm Impedance Bass Speaker - Black

Special features of the universal woofer For low frequency applications Can be installed in power boxes. 100 watts. 12 inches. Technical data SP-302PA. Impedance (Z): 8Ω Frequency range: f3 - 4000 Hz. Resonant frequency (fs): 45 Hz. Rated power (RMS): 100 W Music power (MAX): 200 W Sound pressure: 90 dB/W/m. Compliance (Cms): 0.15mm/N Moving mass (mms): 57 g Mechanical quality (Qms): 2, 2. Electrical Grade (Qes): 1.47 Total quality (Qts): 0.89 Equivalent volume (vas): 51 L. DC Resistor. (Re): 7.7Ω Force factor (W x L): 10.50 Tm. Voice coil ind. (Le): 0.5 mH. Voice coil diameter Diameter: 38 mm. Voice coil support: aluminium. Linear deflection (XMAX): 2.5 mm. Eff. Membrane area (Sd): 542 cm². Magnet Weight: 850g Magnet diameter: 119 mm. Installation opening: diameter 280 mm. Installation depth: 116 mm. Dimensions: diameter 303 mm x 125 mm. Outer diameter: 303 mm. Width: diameter 303 mm. Depth: 125 mm. Permitted Operating temperature: 0 - 40 °C. Weight: 2.36 kg. Box contents: 1 Speaker type: 12" MONACOR In terms of quality, MONACOR International leaves nothing to chance and relies on its own strengths. We ensure maximum safety through an offensive quality policy. Tight tolerance limits as well as extensive goods controls are supported and documented by accredited test laboratories. This means for you: high standards, for all items .
