Sandvik Coromant SL-266RKF-323222-16 CoroThread 266 head for thread turning

Product Description Part of the CoroThread 266 product family. CoroThread 266 is designed with an iLock interface to combat the extreme forces placed upon the insert in the threading operations. The tool guarantees excellent insert stability for ultimate accuracy, surface finish and product consistency. PRODUCT SPECIFICATION: ADINTMS, Adaptive Interface Machine Direction: SL head (screw mounted) -size 32 ; ALP, Axial Clearance Angle: -15 deg ; CNSC, Coolant Entry Style Code: 1: axial concentric entry ; CP, Coolant Pressure: 10 bar ; CP, Coolant Pressure: 145.038 lbf/in2 ; CUTINT_MASTER, Part 2 Of Cutting Item Interface Identifiers: CoroThread -internal size 16 (266.RL-16) ; DCON, Connection Diameter: 32 mm ; DCON, Connection Diameter: 1.25984 inch ; DMIN1, Minimum Bore Diameter: 40 mm ; DMIN1, Minimum Bore Diameter: 1.5748 inch ; HAND, Hand: R ; HF, Functional Height: 0 mm ; HF, Functional Height: 0 inch ; LF, Functional Length: 32 mm ; LF, Functional Length: 1.25984 inch ; OHX, Maximum Overhang: 32 mm ; OHX, Maximum Overhang: 1.25984 inch ; THCA, Thread Helix Correction Angle: 1 deg ; TQ, Torque: 3.0 Nm ; TQ, Torque: 2.21269 ft lbs ; WF, Functional Width: 22 mm ; WF, Functional Width: 0.866142 inch ; WT, Weight Of Item: 0.141 kg ; WT, Weight Of Item: 0.3102 lbs ; Box Contains SL-266RKF-323222-16 + incl. in box: 5513 020-13, Screw, (pcs. = 1, incl.); 5322 390-11, Right hand shim, (pcs. = 1, incl.); 5512 032-05, Shim screw, (pcs. = 1, incl.); 5680 049-05, Key, (pcs. = 1, incl.);
