Schneider Electric Residual Current Circuit Breaker ACTI9 iID, 4P, 63A, 300mA, Type A, A9Z24463

Residual current circuit breaker Acti 9 iID, 1.5kA (IEC/EN 61008-1). 4-pin, rated current 63A, ground fault sensitivity 300mA, ground fault protection class type A, operating voltage (Ue) 400V AC, insulation voltage (Ui) 500V AC. Ensures additional protection when touching directly (≤ 30mA). Error protection in case of indirect touch, e.g. in case of insulation faults (≥ 100 mA, ≤ 300 mA). Error protection in construction power distributors (500mA). Switching and disconnecting circuits. Jump circuit for low-wear switching of the contacts. With mechanical front error message indicator (VisiTrip) to indicate overload or short circuit triggers. Safe contact display (VisiSafe) of the residual current circuit breaker, when the indicator is green indicator, safety of voltage clearance on the outlet side. Test button for regular checking of the function. Double terminals for connecting cables or phase rails on both sides. Easy removal of the individual device with installed phase rail, thanks to the front accessible fastener. Additional stackable auxiliary modules (optional)- low voltage release (iMN), surge release (iMSU), working current trigger (iMX), auxiliary switch for status message (iOF), error message switch (iSD). Tool-free mounting on the left side of the device. Colour: RAL 9003. The residual current circuit breaker iID meets the following standards - IEC/EN 61008-1 and IEC/EN 60947-2. Furthermore, this series is VDE certified.
