Schneider Electric Residual current circuit breaker IDK 2P 40A 30MA type A, A9Z01240

Residual current circuit breaker, 1.5 kA (IEC/EN 61008-1). 2-pin, rated current 40A, earth fault sensitivity 30mA, earth circuit protection class type A, operating voltage (Ue) 230V AC, insulation voltage (Ui) 500V AC. Ensures additional protection when touching directly (≤ 30 mA). Error protection in case of indirect touch, e.g. in case of insulation errors (≥ 100 mA, ≤ 300 mA). Error protection in building power distributors (500 mA). Switch and disconnect circuits. Jump circuit for low-wear switching of contacts. With mechanical front error message indicator (VisiTrip) to display triggers caused by overload or short circuit. Safe contact display (VisiSafe) of the residual current circuit breaker, with green display safety of the voltage freedom on the output side. Test button for regular testing of function. Double terminals for connecting cables or phase rails on both sides. Easy removal of the single device when the phase rail is installed, thanks to the front mounting element. Additional auxiliary modules (optional) - Low voltage trigger (iMN), surge trigger (iMSU), working current trigger (iMX), auxiliary switch for status message (iOF), error message switch (iSD). Tool-free mounting on the left side of the device. Colour RAL 9003. The residual current circuit breaker meets the following standards: IEC/EN 61008-1 and IEC/EN 60947-2. Furthermore, this series is VDE certified.
