TROTEC EC 060 V to + 250 °C Thermal Imaging Camera

Technical specifications: Measuring range from -20 °C to + 250 °C. Accuracy: ±2°C, ±2% of the reading Sensor type: Focal plan matrix (FPA), non-cooled microbolometer Sensor resolution : 160 x 120 pixels Spectral range: 8-14μm Field of view (FOV) : 20° x 15° Space Resolution: 2.2 mrad High thermal resolution from 0.08°C to 30°C. Manual focus Min. Focus: 0.10 m Fully radiometric measurements Scanning frequency up to 50/60 Hz for real-time display Maintenance-free operation thanks to the uncooled microbolometer technology Built-in digital camera for visibility: colour representation 680 x 480 pixels, integrated lighting Image representation: pseudo-colours, 6 colour palettes. Display options: IR image, visible image, different DuoVision fusion options for overlapping images File format: IR radiometric 14-bit Laser type: AlGalnP semiconductor laser diode, 1mw/635nm red Classification: Class 2 Battery type: standard Li-ion rechargeable, interchangeable Battery life: ≈ 3.0 hours Integrated laser viewfinder Ergonomic and ultra-light Automatic temperature monitoring (extremes recognization) Large 3" TFT screen with articulated liquid crystals Memory card included for storing thousands of images Temp. Operating temperature: -15°C to +50°C. Storage Temperature: -40°C to +70°C Protection : IP 54 IEC 529 Shock / vibration resistance: 25 g IEC 68-2-29 / 2 g IEC 68-2-6 Dimensions : 175 x 55 x 160 mm Weight: 500 g
