GUDE 1121-1 Dual Switched PDU with Measurement & Monitoring

Dual switched PDU with integrated measurement and monitoring functionality. 2 AV devices can be powered and switched individually. Easy and fast setup with free drivers for leading AV and IT control systems. Precise energy measurement and monitoring of temperature and humidity by plug-n-play sensors. Remote reboots and automatic switching of power supply. • 2 load outputs can be switched individually on the device, via HTTP(S), SNMP, ModbusTCP as well as via command line interface via Telnet, SSH and MQTT • Switching state and switch-on delay (0...9999 seconds) adjustable for each power connection after power failure. • Current peaks during simultaneous switching processes are prevented by an automatic latency time of 1 second • Programmable schedules and on/off sequences - 2 channel watchdog, each power port can be assigned its own watchdog. • Load outputs can be switched when preset sensor thresholds are exceeded • Connection for plug-n-play sensors for monitoring (temperature, humidity, air pressure). • Input side measurement of current, voltage, phase angle, power factor, frequency, active, apparent and reactive power. • 2 energy meters, one counter counts permanently, the other is resettable. • Integrated surge protection prevents damage to the device and connected loads (L-N 10 kA), status can be accessed via network • Durable high-inrush relays prevent relay contacts from welding at inrush current peaks • Buzzer for acoustic alarm when sensor thresholds are exceeded. • Generation of status messages and alarms (email, syslog, SNMP traps MQTT 3.1.1, SSH, Telnet) • Encrypted emails (SSL, STARTTLS) • Access protection through IP access control • SNMPv1, v2c, v3 (queries/traps)
