InLine Inline USB 3.2 Gen.1 Industrial Hub with 10 Ports, Aluminium Housing, DIN Rail Mount, Active USB Hub with Power Supply, 5Gb/s, 35396C

The InLine USB 3.2 Gen.1 Industrial Hu b is the optimal choice for demanding applications in industrial and technical environments. Equipped with ten USB-A 3.2 Gen.1 ports, it supports data transfer of up to 5 Gb/s, providing high performance for professional users. The sturdy aluminium housing reliably protects against dust, shocks and mechanical influences - ideal for use in control cabinets, workshops or on industrial DIN rails. Thanks to the integrated protection mechanisms against short circuit, overvoltage and electrostatic discharge (ESD), it ensures safe continuous operation. The mounting is done via a DIN rail or wall bracket. The supplied power supply (12 V / 3 A) and an alternative terminal connection allow flexible integration into existing systems. Additional Technical Specifications: Chipset: VL817*3 Inputs: 1x USB B port for connecting to host computer, 1x DC IN (5.5 x 2.5mm), 1x alternative 2-pin terminal connector Outputs: 10x USB-A 3.2 Gen.1 ports (5 Gb/s), BC1.2 Charging specification: Yes (max. 5 V / 2 A per port). Protection mechanisms: short circuit, over current, over voltage, ESD/anti-static protection: 350 W Casing: aluminium, black. Mounting: DIN rail or wall bracket. LED indicator: yes. Plug & Play: No drivers required Standby Power Consumption: 0.07W Operating temperature: -40°C to +85°C. Storage temperature: -40°C to +125°C. Humidity: 10-85% (non-condensing) Operating systems: Windows, MacOS, Linux. Dimensions: 164 x 68 x 28 mm. Weight: 227 g Package includes: 1x InLine USB 3.2 Gen.1 industrial hub, 10 port, aluminium housing, with power supply. 1 x USB-A to USB-B cable, 1 m. 1 x mounting kit. 1 x DIN rail 10 cm and clip. 1 x terminal block. 1 x external power supply 12 V / 4 A. 1 x user manual in German/English. External power supply (power supply): Type: external power supply. Input voltage: 100-240V AC, 50/60Hz Output voltage: 20.0 V DC. Output current: max. 3.0 A. Output power: 60.0W Average operating efficiency: 92.62% Low load efficiency (10%): 91.35% Power consumption at zero load: 0.081 W
