ABB Protecta Plus D13 15-M 65 Modbus Energy Meter • 3-Phase 65A Direct Connected • 4-Quadrant MID Class B • 1 Digital in / 1 Digital Out • DIN Rail 3 Modules • 2CMA241765R1000

3-PHASE DIRECT CONNECTED ENERGY METER (UP TO 65A) – Designed for 3-phase, 4-pole systems (220–240 V N-L / 380–415 V L-L), direct connected up to 65 A. Suitable for commercial buildings, industrial panels and sub-metering applications requiring reliable performance.

MID CERTIFIED 4-QUADRANT MEASUREMENT – Class B (±1%) accuracy for active energy in accordance with MID and EN 50470-3, and Class 2 for reactive energy per IEC 62053-23. Measures import and export of active, reactive and apparent energy.

MODBUS RTU COMMUNICATION WITH DIGITAL I/O – Integrated Modbus RTU interface for connection to building management and energy monitoring systems. Supports multi-tariff operation via external tariff control. Includes 1 digital input and 1 digital output for pulse or alarm functions.

COMPACT & ROBUST DIN RAIL DESIGN – Slim 3-module width (52.5 mm) for space-saving DIN rail installation. IP20 protection, operating temperature −40 °C to +70 °C, low power consumption (0.82 W) and housing components manufactured with at least 70% recycled plastic.

ABB PROTECTA PLUS SYSTEM – Part of the ABB Protecta Plus modular distribution system for indoor installations, offering high internal accessibility, removable internal modules for simplified wiring, insulated neutral and earth bars, and an expandable cabinet concept for flexible electrical distribution solutions.
