InLine ® Gigabit Network Card M12 x Coded PCIe x1 2.1 PoE+ 51124I

The InLine® Gigabit Network Card is specifically designed for robust and reliable network connections in industrial environments. Thanks to the M12 x coded connector, it provides a secure and durable connection ideal for use in machinery, control systems and monitoring solutions. With a data rate of up to 2.5 Gb/s via the PCIe 2.1 x1 interface, it ensures fast and stable transmission of large amounts of data. The integrated PoE+ support (IEEE 802.3af/802.3at) allows connected devices such as surveillance cameras, sensors or access points to be powered directly from the network cable – no separate power source is required. Additional features such as Jumbo Frames (up to 16KB) for more efficient data transmission, VLAN tagging for network segmentation, Wake-on-LAN for remote system booting, and PXE support for network-based booting make the card a versatile solution for demanding network environments. Technical data: External: 1x M12 socket, 8-pin, x-coded. Internal: 1 x PCI Express x1 (2.1), 1 x SATA 15-pin power connector Bus type: PCIe v2.1, x1-Lane (can be used in x1, x4, x8, x16 slots). Chipset: Realtek RTL8125B. Supported protocols: IPv4, IPv6 LED: indicator for action (green) and connection (orange). Supported IEEE standards: IEEE 802.3 (Ethernet), IEEE 802.3u (Fast Ethernet), IEEE 802.3ab (Gigabit Ethernet) IEEE 802.3x (Flow Control), IEEE 802.1Q (VLAN). IEEE 802.3af (PoE) / 802.3at (PoE+). IEEE 802.1P Layer 2 Priority Encoding - Prioritize network: control QoS efficiently Advanced functions: Supports PXE (Preboot Execution Environment) Supports RealWoW (Remote Wake-on-LAN over the Internet) Supports crossover detection and automatic correction Supports Microsoft NDIS5/NDIS6 Checksum Offload (IPv4, IPv6, TCP, UDP) Jumbo frames: up to 16 KB. Environmental conditions: Operating temperature: 0°C to 55°C. Storage temperature: -40°C to 70°C. Maximum humidity: 90% Supported Operating Systems: Windows: 11, 10, 8.1, 8, 7 (32/64 bit). Linux: Native support for Fedora, SUSE, Ubuntu, Red Hat DOS and Novell
