SDKDZKG HDMI ARC Audio Extractor, HDMI ARC Converter Adapter with Digital Optical Toslink SPDIF Coaxial and Analog 3.5mm L/R Stereo Audio for HDTV Amplifier Soundbar Speaker (SDK-A802)

HDMI ARC Function : SDKDZKG HDMI ARC Audio Return Converter connects to the HDMI ARC port of the TV set and returns the audio signal from the TV set to the Soundbar, Amplifier system, Stereo Headphones, Home theatre and other devices via Optical, Coaxial, R/L Stereo and 3.5mm audio interfaces, which is a perfect solution to the problem that TVs without an audio output port cannot be connected to a sound system. Note: The TV must have ARC function and HDMI ARC port. TVs without ARC function cannot use the ARC input port of this product.

192KHz Sampling Rate : SDK-A802 Audio Extractor Supports Sampling Rate at 32 KHz, 44.1 KHz, 48 KHz, 96 KHz, and 192 KHz, and 24-bit S/PDIF Incoming Bit Stream on Left and Right Channels. which can provide higher quality sound signals for a more realistic, detailed and richer music experience. (Please use AGW26 standard HDMI 1.4 cable)

Simultaneous Audio Output : The ARC Audio Converter Adapter has 4 audio output ports (Optical TOSLINK SPDIF + Coaxial + RCA (L/R) + 3.5mm Audio) and can output audio signals simultaneously. Before using the RCA (L/R) and 3.5mm stereo headphone jacks, please set the TV's audio output to PCM or LPCM, the volume of which can be controlled via the TV (CEC). When using the Optical TOSLINK SPDIF and Coaxial jacks, the volume cannot be controlled via the TV or remote control, and you need to control the volume via the zone of the device connected to the output.

Support 5.1 Channels : The optical and coaxial interface of the SDKDZKG HDMI ARC audio Converter supports 5.1CH output. Please make sure that the video source is 5.1CH and the TV audio output is set to 5.1CH. Note: Set the optical port on the TV to source output (outputs unaltered compressed audio).

Wide Compatibility : SDKDZKG ARC Extractor input is compatible with all ARC-enabled HDTVS, and its output is compatible with devices such as Soundbar, Amplifier, Speaker, Headphone, Home theater systems, and more. All you need is an ARC-enabled HDMI cable to easily create your home theater. Note: The adapter needs to be connected to the HDMI ARC port of the HDTV and the adapter switch is switched to “ON”. The ARC function of the HDTV must be on (operable via remote control).

What We Offer : 1 x SDKDZKG ARC Audio Converter , 1 x USB Power Cable, 1 x Users Manual, 18 Month warranty, and 24-Hour friendly customer service.
