HUAWEI Huawei 5G CPE MAX 5 H352-381 & AX3 WiFi 6 Access Point

The 5G CPE H352-381 is a wireless 5G gateway for multiple users in homes or small household office environments. It allows users to access the Internet. The H352-381 supports 3GPP Release 16 with LTE UE downlink category 20 and uplink category 13. The supported service features are as follows: 5G SA NR: downlink maximum 3CC (300M), 4x4 MIMO, 256 QAM, peak rate: 5.4 Gbit/s (DL/UL subframe configuration 8:2) .Uplink maximum 2CC (200 M) 2x2 MIMO, 256 QAM, peak rate: 500 Mbps (DL/UL subframe configuration 8:2) NSA NR: downlink up to 2CC (200M), 4x4 MIMO, 256 QAM, peak rate: 3.6 Gbps (DL/UL subframe configuration 8:2) Uplink 1CC (100M), 1 Tx, 256 QAM, peak rate: 125 Mbps (DL/UL subframe Configuration 8:2) LTE: downlink maximum 4CC, 4x4 MIMO (different frequency bands support different MIMO modes), 256 QAM, peak rate: 1.6 Gbit/s (FDD frequency bands, 20+20+20+20MHz, 4x4MIMO, maximum 16 streams) .Uplink 1CC, 1Tx, 64 QAM, peak rate: 75 Mbps (FDD frequency bands, 20MHz) 4G only: downlink 5CC, 4x4 MIMO (different frequency bands support different MIMO modes), 256 QAM, peak rate: 2 Gbit/s (FDD frequency bands, 20+20+20+20MHz, 4x4MIMO, maximum 20 streams) .Uplink 2CC, 1Tx, 64 QAM, peak rate: 150 Mbps (FDD frequency bands, 20+20 MHz) The actual data rate varies depending on network configuration. 5G: n1/ n3/ n5/ n8/ n20/n28/ n38/ n40/ n41/ n75/ n77/ n78/ n79/ n80/ n81/ n82/ n83/ n84LTE: B1/ B3/ B5/ B7/ B8/ B18/ B19/ B20/ B26/ B28/ B32/ B34/ B38/ B39/ B40/ B41/ B42/ B43WLAN: 2.422GHz—2.482 GHz, WLAN is only used for user installation and configuration. If the user accesses the Internet via this WLAN, performance cannot be guaranteed. Connect the indoor router to the H352-381 first and then connect the indoor router's WiFi to access the Internet
