MEPA Shower Tray Set Mounting Frame SF RE 3S+ Universal - Set for Soundproofing Installation of Extra and Super Flat Rectangular Shower Trays Made of Steel, Acrylic, Mineral Cast - 182123

MEPA SF RE 3s+ Universal Shower Tray Set Mounting Frame Set for sound-absorbing installation of extra and super flat rectangular shower trays made of steel, acrylic, mineral cast. Proven sound insulation via sound certificate for steel and mineral casts, meets the requirements for sound insulation according to DIN 4109, VDI 4100, for shower trays from 700 x 700 mm to 1200 x 1200 mm, height adjustable from 70 mm to 195 mm, with accessories height adjustable. from 55 mm Up to 235 mm, ADS (anti-rotation and sound insulation system), sound-insulated bath edge support, bath edge seal according to DIN 18534. Technical data: Suitable for: shower trays Dimensions: 70 x 70 cm - 120 x 120 cm. Installation height: from 70 to 195 mm. Height adjustment: 125 mm. Bath body: 70 x 70 cm - 120 x 120 cm. Item number: 182123. Box contents: 1 mounting frame [8 height-adjustable screw feet, 1 EasyLift, 1 corner crossbar, 4 floor tabs, mounting material, 8 adapter sleeves (25 mm riser), 8 adapter sleeves (50 mm riser)] 9 ADS caps with Sylomer backing 1 roll of Aquaproof Type II (length 3.80 m, butyl sealing tape in fleece film composite, adhesive on both sides, mounting accessories). 1 roll of sound insulation strips (length 3.80 m). 1 roll of tile divider strips (length 3.80 m, self-adhesive). Anti-drone mats, 6 mat cuts (bitumen foil approx. 8 kg/m², laminated with polyethylene on one side, self-adhesive). Notes: For shower trays made of steel and mineral cast from 700 x 700 mm to 1200 x 1200 mm, for shower trays made of acrylic with smooth bath edge surface from 700 x 700 mm to 1000 x 1000 mm, the universal mounting frame is designed for shower trays whose flatness of the edge surface and/or its straightness of the bottom edge does not exceed a deviation of 3 mm, with mineral cast tubs, it must be ensured that there is a bearing contact point every 60 cm. Tubs with non-supporting ribs are not suitable. The tub must be approved by the manufacturer for mounting with bath feet; for acrylic trays with at least an edge length of 1000 mm, the mounting frame SF acrylic (item no. 150 183) is generally used, test procedures and procedures for determining geometric deviations, see DIN EN 249 Annex A. Commonly this level of steel/mineral cast and by some acrylic tub manufacturers, but must be checked independently
