Fanmusic TOPPING E70 DSD512 ES9028PRO Bluetooth 5.1 THD+N<0.00006% Support LDAC Transmission DAC XU316 RCA&XLR Output PCM768kHz Decoder (Silver)

Silver, E70

Price data last checked 76 day(s) ago - refreshing...

View at Amazon

Price History & Forecast

No Price Data Available

Price history will appear here once data is collected from Amazon.

Price Distribution

No price data available for histogram

Description
Specifications: USB IN PCM: 16-32bit / 44.1 - 768kHz DSD (Native): DSD64 - DSD512 DSD (DoP): DSD64 - DSD256 MQA: Renderer, MQA, MQA Studio IIS IN PCM: 16 - 32bit / 44.1kHz - 768kHz DSD (Native): DSD64 - DSD1024 DSD (DoP): DSD64 - DSD256 MQA: Not supported Coax/ Opt/ AES IN PCM: 16 - 24bit / 44.1kHz - 192kHz DSD (Native): Not supported DSD (DoP): DSD64 MQA: Renderer, MQA, MQA Studio Bluetooth: AAC / SBC / APTX / APTX LL / APTX HD / LDAC Line out RCA decoding parameters (USB IN @96kHz) THD+N@A-wt: <0.00007% @1kHz THD@No-wt 90kBw: <0.0008% @20-20kHz SNR@A-wt: 127dB @1kHz Dynamic range @A-wt: 127dB @1kHz Frequency response 20Hz - 20kHz (±0.1dB) 20Hz - 40kHz (±0.3dB) Output level 2.1Vrms @0dBFS (4V Mode) 2.6Vrms @0dBFS (5V Mode) Noise @A-wt: <1.3uVrms Crosstalk: -124dB @1kHz Channel balance: 0.3dB Output impedance: 100Ω Line out XLR decoding parameters (USB IN @96kHz) THD+N@A-wt: <0.00005% @1kHz THD@No-wt 90kBw: <0.0003% @20-20kHz SNR@A-wt: 134dB @1kHz Dynamic range @A-wt: 134dB @1kHz Frequency response 20Hz - 20kHz (±0.1dB) 20Hz - 40kHz (±0.3dB) Noise @A-wt: <1.1uVrms Crosstalk: -139dB @1kHz Channel balance: 0.3dB Output impedance: 100Ω

Key Features

Super audio reproduction ability with ultra low distortion<br> The E70 uses ESS SABRE flagship DAC ES9028PRO. <br> ES9028PRO has a 32-bit 8-channel HyperStream I1 architecture. In the application of E70, <br> every 4 channels are connected in parallel as one channel,achieving high performance and high sound quality at the same time.<br>

Brand new IN conversion<br> A brand new IN conversion circuit is designed for better quality audio reproduction. <br> The unique circuit design provided lower distortion,lower noise while occupying less space. <br> The new circuit is pushed close to the limit of physics so that we are able to squeeze out the last bit of performance of the DAC chip.<br>

LDAC 24bit96kHz Bluetooth transmission <br> E70 has the certification of Hi-Res Audio Wireless and LDAC. <br> It uses newest QCC5125 chipset to support LDACIAAC/SBC/aptX/aptX LL/ aptX HD/aptX Adaptive protocol by Bluetooth 5.1.<br> To get even better sound quality from Bluetooth,we abandon the built-in DAC of QCC5125 and connect it's digital signal to ES9028PRO to decode.<br>

Newest XMOS XU316 support DSD512&PCM7 68kHz <br> USB input of E70 has a wide range of compatibllity: Windows 10, Windows11, MAC, Linux, lOS, Android can be plug and play. <br> Only for Windows ASIO applications, you need to install the driver and set it up. <br> The USB hardware is based on newest XMOS XU316 and Thesycon custom driver (applicable to Windows, other systems are free of driver), <br> which is stable and reliable.<br>

12V Trigger interface<br> The E70 is equipped with a 12V Trigger interface, which has both active control (Trigger out) and passive control (Trigger in). <br> With only one easy-to-obtain 3.5mm to 3.5mm cable, <br> the E70 can be turned on and off synchronously with other devices equipped with a 12V Trigger interface.<br> It is especially convenient when used with amplifiers, especially the L70.<br>

Product Specifications
Brand
Fanmusic
Model
E70
Colour
Silver
ASIN
B0BKPQSZPL
Category
Electronics & Photo > Hi-Fi & Home Audio > Accessories > Digital-Analog Converters
Domain
Amazon UK
Listed Since
27 October 2022
