SolaMr Battery Equalizer Voltage Balancer 12V/24V/48V/60V/72V/96V Packs for Lead Acid /LiFePO4 and Lithium Batteries for Solar Charging Systems- PLC-10

● Battery equalizer for gel/flood/AGM lead-acid and lithium batteries in series or parallel to maintain battery voltage balance. ● When two or more series/parallel batteries are in charge/discharge/idle state. The battery voltages may be different: one battery voltage is high, and one battery voltage is low. ● When the cell equalizer detects a voltage of 50mV between two cells, it will equalize/balance the cell voltages. ● Shunt current from one battery (higher voltage battery) to another battery (lower voltage battery). until their battery voltages become almost the same. ● This will improve battery performance and prolong battery life. Specifications: Model: PLC-10 Battery Nominal Voltage: 2 x 12V Optimized Current: 0-10A Rated Voltage Range : 7-18V Quiescent current: 10mA Connection method: parallel or series Product size: 85*75*30mm Product weight: 160g Protection: reverse polarity protection Package List: 1 x Battery Balancer 1 x User Manual
