ZHANGQING PoE Injector 12 Port with 48V 60W Power Supply & Operate in Mode B (Pin 4/5 Plus 7/8 Minus), Passive Midspan Power over Ethernet Injector with 10/100M Data & 19 Inch 1U Rackmount Size, POE-12-48V60W

● POE-12-48V60W Power over Ethernet injector is support to IEEE 802.3af passive PoE devices when it work with 48-volt power supply; For 24-volt passive PoE devices please refer to POE-12-24V60W or POE-12-24V120W; No power supply option please see POE-12-1U.

● The POE-12-1U Power over Ethernet injector allows 10/100 Mbps data rate and 19 inches 1U rack mount size, which is suitable for IP cameras, VoIP phones, Wi-Fi access points and so on. Using a 12-port PoE injector can simplify network management by reducing the number of power sources that need to be monitored and maintained.

● The rack-mounted, 1U high POE injector features an LED power indicator, 12 LAN and 12 LAN+POE ports, and is compatible with any Ethernet switch and standard 2.1mm x 5.5mm power connectors.

● POE-12-1U PoE injector 12 port always provides power to ① Mikrotik, Ubiquiti, and similar 24v devices (24v power input); ② OpenMesh and similar 18V devices; ③ IP Cameras - most use 48V (802.3af PoE); ④ IP Phones - most use 48v (802.3af PoE); ⑤ WiFi Access Points - like Aruba, Cisco, HP - IEEE 802.3af.

● The POE-12-1U with 2.1x5.5mm standard power connector and same voltage is for the all ports; 650 ma automatic resettable fuse on each port.
