Frankberg 2x Brake Caliper Disc Brake Front Left Right with Bracket (hole spacing 122mm) Compatible with 3 Series E46 316i 318d 318i 320d 320i 323i Replace# 14134043

AttentionFitment in bullet points are only partial summery of the complete range in the Partfinder! Before making a purchase, please check the "AmazonConfirmedFit" at the top of the webpage. You can identify your vehicle either by entering your vehicle’s licence plate number (REG) or by entering the model, platform, and engine size. Only proceed with your Orr if you see the green "This fits" indicator. A red warning means the part is not compatible – please do not place an Orr!

SpecificationReference Number: 19-B1618, 14134043, 141.34043, 19-B1619, 14134044, 141.34044; Installation Position: Front Axle Left Right

Technical Info.Brake system: ATE; Hole spacing of the bracket (Center-to-center) [mm]: Approx. 122; number of pistons: 1; Piston Outer Diametre [mm]: Approx. 53,95-0.02; Brake Disc Thickness [mm]: Approx. 22; Connection size for brake fluid inlet [mm]: M10X1; Connection size for venting [mm]: M8X1.25; Maximum Diametre of the brake disc [mm]: Approx. 275; Width of the groove for brake disc mounting: Approx. 25,5; Accessories: with Bracket; Piston Material: Metal

Technical AdvantagesStrict quality control, fully automated production line certified by IATF 16949, precision drilling process that accurately replicates original factory specifications, ensuring assembly and long-term reliability for use.

Vehicle FitmentCompatible with 3 Series Coupe E36 318is 320i 323i 325i 328i 1.8L-2.8L 1992-1999, 3 Series E36 318i 318is 318tds 320i 323i 2.5 325i 325td 325tds 328i 1.7L-2.8L 1990-1998, 3 Series E46 316i 318d 318i 320d 320i 323i 325i 325xi 328i 1.6L-2.8L 1998-2005, 3 Series Cabriolet E36 320i 323i 325i 328i 2.0L-2.8L 1993-1999, 3 Series Cabriolet E46 318 Ci 320 Cd 320 Ci 323 Ci 325 Ci 2.0L-2.5L 2000-2008, 3 Series Compact E46 316 Ti 318 Ti 318td 320td 325 Ti 1.6L-2.5L 2001-2005

Vehicle FitmentCompatible with 3 Series Coupe E46 316 Ci 318 Ci 320 Cd 320 Ci 323 Ci 325 Ci 328 Ci 1.6L-2.8L 1999-2006, 3 Series Touring E36 316i 318i 318tds 320i 323i 325tds 328i 1.6L-2.8L 1994-2000, 3 Series Touring E46 316i 318d 318i 320d 320i 325i 325xi 328i 1.8L-2.8L 1999-2005, Z3 Coupe E36 2.8i 3.0i 2.8L 3.0L 1998-2003, Z3 R.o.a.d.s.t.e.r E36 2.0i 2.2i 2.8i 3.0i 2.0L-3.0L 1997-2003, Z4 R.o.a.d.s.t.e.r E85 2.0i 2.2i 2.5 Si 2.5i 3.0i 2.0L-3.0L 2002-2009
