EXSYS EX-1183HMVS-2-4 Ports USB 3.2 Gen1 Metal Hub with Surge Protection

The EX-1183HMVS-2 provides 4 USB 3.2 Gen1 (previously USB 3.0 or 3.1. Gen1) Downstream ports screwable available with 15KV ESD surge protection for each output. The EX-1183HMVS-2 provides up to 4 ports of 1.5A power for charging iPhone, iPad, smartphone and tablets. It is possible to connect up to four external USB peripherals to one USB 3.2 Gen1 port from the notebook, desktop computer or server in the 19" rack. The included cable EX-K1571V (1.5 meter) can be attached to the EX-1183HMVS-2 with thumbscrews without a screwdriver. It can be used in automation, industry and office applications. Thanks to its special housing, the EX-1183HMVS-2 can be screwed to the wall, under a table or into a 19" cabinet (optionally with EX-6099). • USB 3.2 Gen1 metal hub with 4 ports. • 15KV ESD surge protection for each output. • Power supply 12V/3A with DC jack or +7V to +48V with terminal block • Power supply optionally also from USB bus +5V (bus power). • Automatic detection of data transfer rate for connected peripherals • Metal housing for wall, table or optionally on support rail (EX-6099). • 1.5 A current on all 4 ports. • Supports battery charging CDP and DBP mode to simultaneously charge iPhone, iPad from version 4 or above, smartphones and tablets. • Robust metal housing. • 4 x LED USB power indicator. • 1 x LED voltage display. • Chip Set: Genesys GL3523
