enjoy solar enjoysolar SolarV EPEVER® Triron3210N MPPT Solar Charge Controller 30 A, Auto Detection 12/24V, max. PV 100V

Highlights: With the advanced MPPT control algorithm and three-stage adaptive charging mode based on a digital control circle, the TRIRON N N charging controller provides maximum energy from the solar modules and effectively extending the life of the battery, significantly improving system power, and supporting the general performance of electronic protection functions.

[Technical data] Rated voltage: 12/24 VDC; max. PV input power: 390W/12V, 780W/24V; rated charging current: 30A; discharge current: 30A; max. PV Idle Voltage: 100V; RS485 Interface: 5VDC/100mA; USB Interface: 5VDC/ 2.2A; Operating Temperature: -25°C to +45°C; Protection Grade: IP30; Dimensions: 158×238.3×62.79mm; Weight: 1.36kg

[Protection features] Large electronic protection against PV polishing, PV overcharge current PV short circuit; overvoltage and undervoltage of the supply input; battery polishing, overvoltage and overdischarge of the battery, load short circuit and overload; overheating.

[Support battery type] Lead acid battery: AGM, GEL, moved, user; lithium battery

[Certificate and Warranty] CE, RoHs, FCC, IEC62109 and IEC62509; 2 Year Manufacturer's Warranty
