EPEVER ® MPPT XTRA 20A Solar Charge Controller XTRA2210N XDS2, 12V/24V Auto, PV 100V

[Highlights] The XTRA-N series is the latest member of the MPPT controller family of EPEVER. It has improved the design and performance based on the successful previous model Tracer AN series. Thanks to MPPT (Max Power Point Tracking), several maximum power points (MPP) of the solar module are accurately detected, so you can expect 20-30% more power outputs of the solar panel.

[Highlights] The display of the XTRA-N series has three different options: base display (XDB1) and standard display (XDS1) and premium display (XDS2), with the premium display (XDS2) you can set the battery type, the charging voltage parameters and the operating mode for charging directly on the charge controller.

[Technical data] Rated voltage: 12/24/VDC car; Max. PV input power: 260W/12V or 520W/24V; rated charging current: 20A; discharge current: 20A; max. PV Open-circuit voltage: 100 V; RS485 interface: 5 VDC/100 mA; operating temperature: -25 °C to +45 °C; protection class: IP30; dimensions: 217 x 158 x 56.5 mm; weight: 0.96 kg

[Application] Other monitoring and setting options via MT50, eBox (Wifi, Bluetooth or eLog), PC communication cable

[Warranty] 2 year warranty.
