Gira Uni-LED Dimmer Insert 2-Way 540200

Description System 3000 universal LED dimmer insert comfort 2-way features: two independent outputs for two light groups. Switching and dimming incandescent lamps, HV halogen lamps, electronic transformers for halogen or LED lamps, dimmable inductive transformers for halogen or LED lamps, HV LED or CFL lamps. Connection of extension points possible. With system 3000 extension insert 3-wire in combination with a system 3000 control attachment 2-way, both outputs can be operated separately. Automatic or manual adjustment of the dimming principle suitable for the load (phase or phase control). Display of the set operating mode by LED. Light on Switch-on brightness can be permanently saved. Turn on with the last set brightness or saved on brightness. Adjustable minimum brightness. Electronic short circuit protection. Electronic overtemperature protection. Operation with and without neutral conductor connection. Notes: In principle, the operation is
