Inwerang 5MP 4MP Dome Super Hybrid Security Camera HD-TVI/CVI/AHD/960H CCTV Surveillance Security Camera 2.8-12mm Varifocal Lens Outdoor/Indoor 98ft IR Waterproof Day&Night Vision Dome Camera(Gray)

Please notice: This CCTV camera supports 5MP TVI/AHD/CVI/CVBS (960H Analog) 4 Modes of video output. The default video mode is 5MP TVI, please change to corresponding VIDEO MODE by joystick cable according to your DVR before use. Switch to TVI: Press Rightward for 5 Seconds Switch to AHD: Press leftward for 5 Seconds Switch to CVBS: Press Upward for 5 Seconds Switch to CVI: Press Downward for 5 Seconds This is a 5MP@20fps 4in1 camera, please confirm your DVR type, and then use OSD Joystick to switch to corresponding camera video mode. If your DVR only supports 5MP@12.5fps , please use OSD Joystick to switch to 960H mode first, then enter into camera OSD menu to choose 5MP@12.5fps video output. Technical Parameters: - 1/2.5" CMOS sensor, 2560x1920 Effective Pixels - Resolution: 5MP Super HD - Built-in Lens:2.8-12mm Varifocal Lens - IR Leds:36pcs - IR Radiation Distance: 30m(98ft) - Signal System: NTSC - Video Output: 1080P TVI(Switch DIP Cable Change to 1080P AHD/CVI and 960H Analog) - Day &Night: Support (ICR) - Frame Rate: NTSC 30fps (60Hz); PAL 25fps (50HZ) - Min. illumination: 0lux(LED ON) - S/N Ratio: >52dB (AGC off) - Electronic Shutter: Auto 1/50s (1/60s)-1/100,000s - White Balance: Auto - Gain Control: Auto - Waterproof for Indoor/Outdoor - Power Supply: DC12V 1000mA Package included: 1 x Dome camera 1 x Bag of mounting screws 1 x User guide More information: If you have any questions or meet any problems with our product, please don't hesitate to contact us for support.
