Bticino Legrand, Flex'ONE Audio Door Intercom Set, 2-Wire with Linea 3000 Door Station, Power Supply and House Station CLASSE 100 A16M, Door Station Protection Types: IP 54, IK10, 364231

Flex'ONE audio set with door station LINEA 3000 and house station CLASSE 100 A16M. The set in 2-wire technology contains all the necessary parts to realise a single-family house intercom. The extension to a two-family house is done by adding a 2nd home station of your choice. The set consists of: 1 surface-mounted door station LINEA 3000 with front panel made of ZAMAK. Includes 2 call buttons as standard and can be configured as a single or two-family house using a slide switch. Equipped with name plate including brightness controlled backlight (white LEDs) and status LEDs for speaker and door opener. The door opener (max. 30 ohm internal resistor) connects directly to the S+ and S- terminals (18 V, 4 A shock current, 250 mA holding current). The door station can be used using a flush-mounted box (item no. 350020) and accessories (item no. 343061) for flush-mounting. Protection class IP 54, impact resistance IK 10, dimensions: W × H × D: 100 × 190 × 26 mm/ Colour: similar to RAL 9007 - 1 audio power supply - 1 surface-mounted house station Class 100 A16M with handphones. It has 3 sensor buttons for: opening the door, turning on the staircase light (activator required, sold separately) and for turning on or switching the door station. There are also 4 freely configurable additional buttons (for example for an internal intercom system, additional door opener, etc.). 16 melodic call tones can be set. incl. doctor's circuit/automatic door opening function. Different doorbells available for front doorbell and flat doorbell. The volume of the call sound is adjusted by means of the side adjuster. LED indicator for: ringing tone deactivation and door opening status. Surface-mounted using the supplied wall bracket. Table accessories sold separately. Connection for BUS, floor call and additional ring mechanism. Dimensions (W x H x D): 102 × 169 × 29 mm wiring diagram and instruction manual (English language not guaranteed).
