Legrand Smart rack PDU metered 0U, 32A-400V, IEC 320 sockets: 36 x C13 and 12 x C19, 22 kVA max., with real-time power measurement and ambient monitoring

Legrand intelligent metered PDUs have an input measurement that allows accurate measurement of the power consumption of the devices, which can monitor performance and control the growth of the data centre. The overview of the rack power capacity and energy consumption allows you to clearly understand the remaining capacity in the cabinet to facilitate decisions on future growth. Legrand PDUs benefit from Raritan measuring technology and deliver precise measuring performance that delivers a clear picture of energy consumption. The PDUs are certified to ensure a measurement accuracy of +/-1% in real time, so you can be sure that your PDU will provide the necessary information at any time when needed. PDUs provide their devices with continuous power, constantly monitor the voltage level and control the environment. Humidity and temperature sensors can be connected. A control with display allows local access to all measurement data (current, voltage, frequency, temperature/humidity, IP address). A bright colour LCD display signals interference by changing the colour according to the alarm level detected by the iPDU All data can be transferred to smartphones/electronic devices. There are two options: 1. via USB cable and app, 2. Access via standard browser when PDU and device are on the same network. Technical details: Rack height: 0U HD output ports: 36 x IEC-320-C13 & 12 x IEC-320-C19 sockets. Input connections: IEC-309 plug, 32A 3-phase output voltage: 200-240 V. Input voltage: 230/400 V. Input frequency: 50/60 Hz. Length x width x height. 178 x 6 x 5.9 cm. Weight/weight including Packaging: 5966 g / 7380 g
