Jung 1701 SE Mechanism A Relay Switch, 1 Channel

With extension input, for attachments item no. : .. 1700 .., .. 1701 .., .. 1750 D .., .. 1751 BT .., .. 17180 .., .. 17280 .., .. 17181 .., .. 17281 .., DWPM 17360 .., Intended use, switching of lighting and engines. Operation with a suitable attachment From the LB management, installation in device socket according to DIN 49073, product features, connection of extension possible, run-up times adjustable, test operation for functional testing, adaptive zero point circuit, nominal voltage: AC 230 V ~, power frequency: 50/60 Hz, standby power depending on the attachment: approx. 0.1 ... 0.5 W, switching current at 35 °C, ohmsch: 16 A (AC1), minimum switching current AC: 100 mA, connection power, light bulbs: 2300 W, HV halogen lamps: 2300 W, electronic transformers: 1500 W, inductive transformers: 1000 VA, HV LED lamps: type. 500 W, compact fluorescent lamps: type. 500 W, fluorescent lamps uncompromised: 1200 VA, switching current motors: 6 A, capacitive load: 920 VA (115 µF), connection: screw terminals, single-wire: 1 x 0.5 ... 4.0 mm2 x 0.5 ... 2.5 mm2, fine wire without ferrule: 1x 0.5 4.0 mm2 2 x 0.5 ... 2.5 mm2, fine wire with ferrule: 1 x 0.5 ... 4.0 mm22 x 0.5 ... 1.5 mm2, ambient temperature: ?25 ... +45 °C, storage/transport temperature: ?20 ... +70 °C, number of side 6666666Wire item no. 1720 NE: unlimited, extension 3-wire item no. 1723 NE: 5, button: unlimited, run time: without, 1 min, 5 min, 30 min, 60 min
