Lapp Kabel Bund Lapp ÖLFLEX SOLAR XLS-R T BK/RD Solar Cable Twin Cable 20 m 2 x 6 mm²

Ölflex Solar XLS-R T BK/RD solar cable Electrical properties: Rated voltage U0/U according to VDE: AC 600/1000 V / DC 900/1500 V Maximum permitted DC voltage: 1.8 kV DC (conductor/conductor, non-earthed system) Test voltage AC 6.5 kV voltage resistance tests according to EN 50395 Thermal features: Fixed temperature range: -40 °C to +100 °C max. Conductor temperature: Short circuit temperature +200°C Flexible laying temperature: max. -25 °C Themed service life according to EN 60216-2 Thermal pressure resistance according to EN 60811-3-1 Moisture heat test according to EN 60068-2-78 at 85% humidity Mechanical features: Minimum bending radius occasionally moved: 15 x wire diameter. Fixed: 5 x wire diameter. Dynamic penetration: according to requirements profile AK 411.2.3 Annex F Tear resistance: according to requirements profile AK 411.2.3 Annex G Test of insulation and sheath tear resistance as well as elongation: according to EN 60811 Chemical properties Ozone resistance: according to EN 50396 part 8.1.3 procedure B Weather / UV resistance according to HD 605/A1 Fire behaviour flame retardant according to IEC 60332-1-2 Halogen free according to IEC 60754-1 Acid and alkali resistance according to EN 60811-2-1 (oxalic acid and caustic soda) EC guidelines The lines are compliant with EC Directives 2006/95/EC (Low Voltage Directive) and 2002/95/EC and 2011/65/EC (RoHS, Restriction of the use of certain hazardous substances). Installation in the soil. Solar cables can generally be laid in protective pipes suitable for ground installation in the soil if it is ensured that there is no permanent contact with water and waterlogging. The installation of the cables and the correct execution of the cable trench must comply with VDE 0100 Part 520 or comparable standards.
