Mut Electric 701100102 DC SERVO For Valves FANCOIL

The servomotori V3 were progettatati For Home Use of heating and cooling, where it require reduced footprint and ease of assembly. These servomotori are deprived of micro End Of Running And Auxiliary. The closing force of the valve stem is guaranteed through a magnetic coupling. Valves to shutter with manual control, ready for be controlled by these servomotori, can be in any time controlled electrically. It simply unscrew completely the manual knob and screw in place the ring of the servo control electric. All this without the need to empty the plant. Compatible with the mut valves, models FV3, F2 V, V3B, VPR Technical Data: – Version: Modulante – Running linear Max: 7 mm – Max Force.: 180 N – Power Supply: 24 VAC – Power Consumption: 1 W – degree of protection EN60529: IP50 – EN60730 insulation class: II – max temperature. /min. environment: 5 °C/60 °C – Size (mm): 50 x 61 x 92 – Housing material: Self-extinguishing ABS – Gears: Pom Time for running max (sec.): 180 with economic function Power off after 4 minutes of no change in the control signals – Control signal: 0 – 10 VDC; 2 – 10 VDC; Adjustable – Reverse: inversion of the reference signal at 0%, settable – Total length standard cable: 550 mm.
