MERCURY Mercury 305 m CAT6A S/FTP LSZH Network Cable - Purple

Product Description Cat6a oxygen free copper twisted pair data cable with low smoke zero halogen sheath. Individual pair aluminium foil screen and overall braided aluminium screen provide protection from any pair or alien crosstalk. Supplied on a wooden drum reel and marked at 1 metre intervals. This cable is designed for high speed data transmission such as Gigabit Ethernet applications within noisy environments. SPECIFICATION: • Conductor Solid OFC • Strands 8 x 1/0.565mmØ ±2% • Conductor CSA 8 x 0.251mm² • Cable diameter 7.5mmØ • Screen Aluminium/Mylar foil • Braid material Aluminium • Insulation PE 0.385mm thickness • Sheath LSZH 0.55mm thickness • Capacitance 6.6nF/100m • DC resistance @ 20°C 25dB @100m • Attenuation 74.3dB • PSNEXT >72.3dB • ELFEXT >13.8dB • PSELFEXT >10.8dB • Phase delay <570ns • Colour Lilac • Length 305m • Weight 17.4kg Box Contains 1 x 305m Drum of Cat6a S/FTP LSZH Network Cable
