Bosch DHL575C

Operating mode and power Energy efficiency class: C* Average energy consumption: 80.1 kWh/year* Fan efficiency class: C* Lighting efficiency class: A* Grease filter efficiency class: D* Noise min. /max. Normal level: 50/67 dB* Noise values according to EN 60704-3 and EN 60704-2-13 during exhaust air operation: max. Normal level: 67 dB(A) re 1 pW (53 dB(A) re 20 µPa sound pressure). Intensive level: 70 dB(A) re 1 pW (56 dB(A) re 20 µPa sound pressure). Optional exhaust or recirculation operation. An activated carbon filter is required for recirculation operation. Double-flooded high-performance blower 3 power levels and 1 intensity level. Intensive levels with automatic reset Fan performance during exhaust air operation according to EN 61591: max. Normal level 560 m³/h, intensive level 610 m³/h. Comfort Illumination: 244 lux Colour temperature: 4000K Workplace lighting with 2 x LED spotlights 1 W. Warm white Electronic control Short stroke buttons with LED indicator. Edge extraction. Stainless steel filter cover Environment and safety Metal grease filter, dishwasher safe. Technical information: For mounting in a kitchen cabinet Dimensions: Exhaust pipe diameter 150 mm, 120 mm. Total connection value: 252 W. Device dimensions exhaust air (H x W x D): 418 x 520 x 300 mm. Device dimensions circulating air with starter set (H x W x D): 418 x 520 x 300 mm. Installation dimensions (H x W x D): 418 x 496 x 264 mm. .
